| Cargo Module |
(A3+BL) Bolsters 3 pairs+bolter lock, (A4+BL) Bolsters 4 pairs+bolster lock, (A4Ex+BL) Frame extension, bolsters 4 pairs+bolster lock, (A5Ex+BL) Trailer with frame extension and 5 pair of bolsters+bolster lock
|
| Couplyng |
(C2) German high type drawbar without hitch, (C3) Austrian low type drawbar without hitch
|
| Bolt |
(K1.1) Bolt on HD swiveling eye 50mm (110×100) only if C2 orC3 drawbar have been chosen, (K2) Bolt on fixed eye 40mm (100×110) only if C2 or C3 drawbar have been chosen, (K3) Bolt on K-80 eye (100×110) only if C2 or C3 drawbar have beel chosen
|
| Wheel set |
(WH3.8) 500/50-17 RF-rim, 8 holes, (WH6.8) 550/45-22,5 RF-rim, 8 holes, (WH7.8) 600/50-22,5 RF-rim, 8 holes, (WH8.8) 500/45-22,5 RF-rim, 8 holes
|
| Drive |
(RWD) Roller-drive, tractor hydraulic, (RWD+) Roller-drive with elect. control system, Without drive
|
| Traffic Requirements |
(TK) Road traffic kit (number plate holder frame with LED-s, wheel stoppers), (WB) Wheel stoppers, Off-road use
|
| Brakes |
(B0) Without brakes, (B1) Hydraulic brakes 2 wheels, (B2) Hydraulic brakes 4 wheels, (B3) Air brakes 2 wheels, (B4) Air brakes 4 wheels
|
| Supply of Hydraulics |
(P1+T2+) Piston pump on the drawbar, 65L @650rpm, Tank, 95L oil-filled with HVLP oil, (P2+T2+) Piston pump on the drawbar, 82L @650rpm, Tank, 95L oil-filled with HVLP oil, (P4+T2+) Piston pump with multiplier on the drawbar, 98 @650rpm, Tank, 95L oil-filled with HVLP oil, (P4PTO+T2+) Piston pump with female-multiplier to PTO, 98L @650rpm, Tank, 95L oil-filler with HVLP oil, (P6+T2+) Load sensing pumps with multiplier on the drawbar, 120L @650rpm, Tank, 95L oil-filled with HVLP oil, (P6PTO+T2+) Load sensing pump with female-multiplier to PTO, 98L @650rpm, Tank, 95 oil-filled with HVLP oil, Trailer and crane connected to tractor hydraulics
|
| Control Unit |
(D1) Platform with back support on the drawbar (PSH option must be selected for crane), Without platform
|
| LED Lights |
(L2) Rear LED lights with Kilpi with flexible arm, reflectors and cover, No Lights
|
| Biomass box |
(Bbox) yes, No biomass box
|
| Parking support legs |
(SJ) Removable parking support leg jack on drawbar, (SL) Removable parking support leg on drawbar
|
| Oil cooling package |
(CP2) Oil cooling package, attached to the tank, only with T2 on T2+, No oil cooling package
|
| Parking brake |
(PB1) Parking brake, actuators at wheels (only with FT11 trailers), No parking brake
|
